GTP-TA-800 Thermal/EMI Absorber Material

Gtp-Ta-800 Offers Hybrid Absorber/Thermal Management Material That Is Used For Emi Mitigation. Designed Using Silicone Gel Binder That Imparts Inherent Tack Typical Of Standard Thermal Gap Fillers. Filler Particle Composition Imparts Both Excellent Thermal Conductivity And Good Emi Suppression In The Microwave Frequency.
The Proprietary Formulation Of Gtp-Ta-800 Is Rohs Compliant And Halogen-Free, Providing Extra Reassurance In Applications Where Hazardous Substances Are Forbidden.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Features and Benefits

● Thermal conductivity:8.0W/m-K

● Thermal conductivity and EMI reduction provide two in one solution

● Natural tacky

● Easy to assembly

● Can add PSA

Applications

● NFC，EMC

● Wireless charging equipment

● Communication equipment

● 5G equipment

● Telecom services,

● AI application

Property	Data	Test Method
Composition	Silicone elastomer
Color	Dark Gray	Visual
Thermal conductive	8.0W.m^-1.K^-1	ASTM D5470
Hardness	50~70 Shore 00	ASTM D2240
Thickness Range(mm)	0.5~5	N/A
Density	5.3 g.cm^-3	ASTM D792
Temperature Range	-40℃～+175℃	N/A
Dielectric Constant@1MHz	9.95	ASTM D150
Flame Rating	UL 94 V-0	UL 94
Volume Resistivity	7*10⁷ ohm-cm	ASTM D257
Tensile Strength	25psi	ASTM D412
Standard Sheet Size	300*400 mm	N/A
The information and statements herein are believed to be reliable but are not to be construed as a warranty or representation for which we assume legal responsibility. Users should undertake sufficient verification and testing to determine the suitability for their own particular purpose of any information or products referred to herein.
