GTP-130 Thermally Conductive Interface Pads

Thermal Conductive Pad
Availability:
Quantity:
Product Description

GTP-130 Series thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. Thermally conductive interface pads flexibility and elasticity make them suited to the coating of the very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.


主图03

Features and Benefits:

.Thermal conductivity 13.0 W/m-K

.High Thermal Conductivity

.Natural tacky

.Good Electrically isolating

.Easy to assembly

.Cost effective

Applications:

 .Computer services: CPU, Heat sink, Memory modules

 .LED Lighting, LCD-TV

. Military Electronics

. Power Supplies

 .Telecom services, Wireless instruments

Property

GTP-130

Unit

Tolerance

Test Method

Composition

Filled silicone elastomer

Color

Grey

Visual

Thermal conductive

13.0

W.m-1.K-1

ASTM D5470

Thickness

30-400(1mil=0.0254mm)

mil

±10%

ASTM D374

0.75-10

mm

ASTM D374

Hardness

50~60

Shore 00

ASTM D2240

Density

3.2

g.cm-3

Temperature Range

-40~+200

Flame Rating

UL 94 HB

UL 94

Breakdown Voltage  (V/mm)

200

V

ASTM D149

Standard Sheet Size

300*300

mm

Tensile Strength

32

psi

ASTM D412

Shelf Life /Months

24

Month

Please contact us for other special requirements  such as :

.With or without adhesive

.Custom die-cut shapes

.Special requirements: hardness, color, thickness, sizes, different structure composition

.Sample request
