GTP-060IM Electronic Ultra Soft Thermal Pad Material
Home » Products » Thermal Conductive Pad » GTP-060IM Electronic Ultra Soft Thermal Pad Material

GTP-060IM Electronic Ultra Soft Thermal Pad Material

GTP-060IM Thermal Pad Material, find complete details about GTP-060IM Electronic Ultra Soft Thermal Pad Material - AMG
Quantity:
Product Description

GTP-060IM Series thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. The Thermal Pad Material flexibility and elasticity make them suited to the coating of the very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.

主图02

Property

GTP-060IM

Unit

Tolerance

Test Method

Composition

Filled silicone elastomer

Color

Multi-color

Visual

Thermal conductive

6.0

W.m-1.K-1

ASTM D5470

Thickness

20-200(1mil=0.0254mm)

mil

±10%

ASTM D374

0.5-5

mm

ASTM D374

Hardness

50~70

Shore 00

ASTM D2240

Density

3.4

g.cm-3

Temperature Range

-40~+200

Breakdown Voltage

>3000(0.3mm~0.5mm)

V

ASTM D149

>5000(>0.5mm)

Flame Rating

UL 94 V-0

UL 94

(UL FileE348291)

Dielectric Constant

12.6

MHz

ASTM D150

Standard Sheet Size

200*400

mm

Volume Resistivity

1013

ohm-cm

ASTM D257

Tensile Strength

32

psi

ASTM D412

Please contact us for other special requirements  such as :

.With or without adhesive

.Custom die-cut shapes

.Special requirements: hardness, color, thickness, sizes, different structure composition

.Sample request
