Applications
● Robot automated assembly
● Automotive industry
● 5G Communication industry
● ABS system
● Military Electronics
● Communication equipment
● Mobile phone CPU
● Memory module
● IGBT and other power modulesTelecom services
● Power semiconductors
Features and Benefits
● High thermal conductivity
● Natural tacky& Low contact resistance
● Full-cured & No oil-bleeding
● High compression
● Suit auto-dispensing equipment
● Meets Rohs specifications
Packing Information
● 30CC syring
● 55CC syring
● 100CC syring
● 300CC cartridge
● 25KG pail
Property | Data | Test Method |
Thermal conductive | 7.0W.m-1.K-1 | ASTM D5470 |
Color | Multi-color | Visual |
Flow Rate, 30cc syringe with no tip attachment 0.100” orifice, 90psi | 12~50 g/min | AMG Test method |
Density | 3.3g.cm-3 | ASTM D792 |
Minimum bond line thickness (mm) | 0.1 | AMG |
Temperature Range | -55℃～+200℃ | — |
Breakdown Voltage (V/mm) | >8000 V | ASTM D149 |
Volume Resistivity | 1013 ohm-cm | ASTM D257 |
Flammability Rating | V-0 | UL 94 (UL FileE348291) |
RoHS Compliant | Yes | AMG Certification |
Optimal Storage: | 25ºC (±10) 50% RH (±10) for 12months shelf life | |
The information and statements herein are believed to be reliable but are not to be construed as a warranty or representation for which we assume legal responsibility. Users should undertake sufficient verification and testing to determine the suitability for their own particular purpose of any information or products referred to herein. | ||
